Automotive Films

Durable and Extraordinary Performance

Using Nano-Ceramic technology developed in joint-study with the Fraunhofer-Gesellschaft of Germany, Hüper Optik Ceramic Series offers a range of high performing solar control films with scratch resistance hardcoat, superb durability while maintaining high total solar energy rejection.

X3 Ceramics

Hüper Optik™ Nano-ceramic series are made up of non-reactive, stable Titanium Nitride (TiN) compounds, which does not fade or corrode. The benefits of Huper Optik® Nano-ceramic series films are:

  • Extraordinary Heat rejection performance
  • Superb Durability
  • Low visible light reflectance
Technical Specifications
Nano Ceramics Series VLT % VLR % (EXT) VLR % (INT) UVR % TSER % U-Value SC SHGC
Hüper Ceramics 05 6 11 11 > 99 70 1.03 0.35 0.3
Hüper Ceramics 15 13 17 16 > 99 71 1.04 0.34 0.29
Hüper Ceramics 20 20 14 14 > 99 66 1.05 0.39 0.34
Hüper Ceramics 30 31 14 11 > 99 60 1.04 0.46 0.4
Hüper Ceramics 40 41 12 9 > 99 53 1.05 0.54 0.47

Data captured using NFRC guidelines and calculated for single pane, 1/8″ (3mm) clear glass. Reported values are taken from representative product samples and are subject to normal manufacturing variances. Actual performance will vary based on a number factors, including glass type and properties.

Nano Ceramics

Hüper Optik™ Nano-ceramic series are made up of non-reactive, stable Titanium Nitride (TiN) compounds, which does not fade or corrode. The benefits of Huper Optik® Nano-ceramic series films are:

  • Superior Heat rejection performance
  • Superb Durability
  • Low visible light reflectance
Technical Specifications
Nano Ceramics Series VLT % VLR % (EXT) VLR % (INT) UVR % TSER % U-Value SC SHGC
Hüper Ceramics 50 53 12 10 > 99 45 1.06 0.63 0.55
Hüper Ceramics 60 61 11 9 > 99 39 1.06 0.71 0.61
Hüper Ceramics 70 73 8 9 > 99 44 1.04 0.64 0.56

Data captured using NFRC guidelines and calculated for single pane, 1/8″ (3mm) clear glass. Reported values are taken from representative product samples and are subject to normal manufacturing variances. Actual performance will vary based on a number factors, including glass type and properties.

Traditional Series

Hüper Optik™ Nano-ceramic series are made up of non-reactive, stable Titanium Nitride (TiN) compounds, which does not fade or corrode. The benefits of Huper Optik® Nano-ceramic series films are:

  • High Heat rejection performance
  • Color aesthetics
  • 99% UV rejection
Technical Specifications
Nano Ceramics Series VLT % VLR % (EXT) VLR % (INT) UVR % TSER % U-Value SC SHGC
Hüper Klassisch 20 27 7 13 > 99 48 1 0.59 0.52
Hüper Klassisch 33 39 7 7 > 99 37 1.06 0.72 0.63
Hüper Klassisch Black 15 17 6 7 > 99 43 1.05 0.65 0.57

Data captured using NFRC guidelines and calculated for single pane, 1/8″ (3mm) clear glass. Reported values are taken from representative product samples and are subject to normal manufacturing variances. Actual performance will vary based on a number factors, including glass type and properties.

For information on other Huper Optik film series (K, CSD), please contact us.
